1.SrSolar Powerwall can be charged by the utility AC 220V/230V and solar roof, the maximum input current of 100A, in the sunny daytime can be charged by the solar energy for the battery, the night storage battery through the inverter for home appliances power supply.
2. Safe backup power supply in case of emergency power failure, the inverter automatically switches to the energy storage system to supply power to household loads.
3. Support 16 storage batteries in parallel to expand capacity to meet different energy needs.
4. Built-in BMS can protect the energy storage battery in any emergency situation and continue to supply power to electrical appliances safely.
5. Intelligent WIFI module, any time at any time to check the solar power generation and battery use situation.
6. The energy storage system can continuously charge the battery through the photovoltaic array to save power expenses and reduce carbon emissions, clean energy everywhere
|
Item
|
5KW
|
10KW
|
|
Model
|
SRKH-5K5B
|
SR-10K10B
|
|
Inverter
|
||
|
Inverter Type
|
5KW Hybrid Inverter
|
10KW Hybrid Inverter
|
|
Output Power
|
5KW
|
10KW
|
|
Output Voltage
|
210V-230V 50Hz AC
|
210V-230V 50Hz AC
|
|
PV Array MPPT Voltage
|
120Vdc-450Vdc
|
120Vdc-450Vdc
|
|
Lithium Battery
|
||
|
Nominal Voltage
|
51.2V
|
51.2V
|
|
Nominal Capacity
|
100Ah
|
200Ah
|
|
Energy
|
5.12KWh
|
10.24KWh
|
|
Max Discharge Current
|
100A
|
100A
|
|
Max Charge Current
|
100A
|
100A
|
|
Charge cut-off voltage
|
58.4V
|
58.4V
|
|
Discharge cutoff voltage
|
40V
|
40V
|
|
Operating temperature
|
-20℃-60℃
|
-20℃-60℃
|
|
Storage temperature
|
0-45℃
|
0-45℃
|
|
Cycle Life
|
6000 times
|
6000 times
|
|
Warranty
|
5 Years
|
5 Years
|
|
Packaging accessories
|
Battery*1pcs
Inverter*1pcs
Manual*1pcs
Mounting Bracket*1 set
RJ48 Cable*1pcs
WIFI Module*1pcs
Mounting screw*6pcs M6
|
|
